Product Description
Capacity
| Users | 30,000 |
|---|---|
| Event Buffer | 100,000 transactions |
RAM
| RAM | 32M |
|---|
Reader Port
| Qty. 4 | 26/34bit Wiegand |
|---|---|
| Qty. 4 | 8bit burst for PIN |
Output Port
| Qty. 2 | 1 Aux FORM-C relay output-SPDT 2A@30V AC |
|---|---|
| Qty. 2 | 1 FORM-C relay output-SPDT 5A@36V DC or 8A@30V AC |
LED
| Indicator | communication, power, status and prox card |
|---|
Environment
| Operating Temperature | 32-113 F (0-45 C) |
|---|---|
| Operating Humidity | 20% to 80% |
Packaging
| Dimensions | 8″ x 6″ x 2 1/2″ |
|---|---|
| Weight | 3 lbs (48 ozs.) |
CPU
| 32bit | MIPS CPU |
|---|
Communication
| Communication | RS485 |
|---|---|
| Communication | TCP/IP |
Input Port
| Qty. 6 | Exit Button #1 |
|---|---|
| Qty. 6 | Door Sensor #1 |
| Qty. 6 | Aux #1 |
| Qty. 6 | Exit Button #2 |
| Qty. 6 | Door Sensor #2 |
| Qty. 6 | 1Aux #2 |
Baud Rate
| RS485 | 9600-57600 baud |
|---|
Power
| Power Supply | 9.6V-14.4V DC, 1A |
|---|
Dimensions
| Length | 10″ (160 mm) |
|---|---|
| Width | 6.6″ (106 mm) |
*Due to continuous technology up gradation, designs and specification are subject to change without notice.
**The photos and images used here are only for reference purpose. The actual product may vary. All Brand names and trademark are the property of their respective owners.
